Salesforce CDC Data Integration – SQLServerCentral

3) Publish and Deliver Events

Whenever a tracked record changes, Salesforce emits a JSON Change Event containing:

5) Replay Missed Events

Each event carries a Replay ID. If your client disconnects, you can reconnect and specify the last Replay ID you received. Salesforce will then replay all missed events (within a retention window of up to 3 days).

This diagram shows the end-to-end workflow of subscribing to Salesforce CDC events. It begins with user authentication, where the web application requests an access token from Salesforce’s OAuth service. After successfully obtaining the token, the application uses it to initiate a CometD handshake. This handshake is a negotiation step that sets up the communication protocol and ensures the client is recognized and allowed to connect securely.

Once the handshake succeeds, the CometD client proceeds to subscribe to the relevant CDC channels. Each Salesforce object you want to track, like Account, Contact, or Opportunity, has its own dedicated channel. The client sends subscription requests for these channels, and the CometD server responds with confirmations to acknowledge that the client is now registered to receive change events for those objects.

After all subscriptions are confirmed, the client establishes a long-polling connection that stays open to listen for incoming notifications. As data changes occur in Salesforce, such as record creations, updates, deletions, or undeletions, CDC channels emit events. These updates are pushed through the CometD server (Salesforce internal Service Bus) to the client in near real-time.

def get_salesforce_session(self):
        # Obtain Salesforce session with access token using OAuth 2.0.
        try:
            token_url = f'{INSTANCE_URL}/services/oauth2/token'
            payload = {
                "grant_type": "client_credentials",
                "client_id": CLIENT_ID,
                "client_secret": CLIENT_SECRET
            }
            response = requests.post(token_url, data=payload)
            response.raise_for_status()
            token_data = response.json()
            access_token = token_data.get("access_token")
            instance_url = token_data.get("instance_url")
            if not access_token or not instance_url:
                raise Exception("Failed to obtain access token or instance URL")
            self.sf = Salesforce(instance_url=instance_url, session_id=access_token)
            logger.info("Successfully authenticated with Salesforce")
            return self.sf
        except Exception as e:
            logger.error(f"Error obtaining Salesforce session: {e}")
            raise

def cometd_handshake(self, cometd_url):
        # Perform single CometD handshake for all channels.
        self.session = self.get_cometd_session()
        handshake_payload = [{
            "version": "1.0",
            "minimumVersion": "0.9",
            "channel": "/meta/handshake",
            "supportedConnectionTypes": ["long-polling"],
            "advice": {"timeout": 60000, "interval": 0}
        }]

        response = self.session.post(cometd_url, json=handshake_payload)
        if response.status_code == 200:
            result = response.json()[0]
            if result.get('successful'):
                self.client_id = result['clientId']
                logger.info(f"CometD handshake successful. Client ID: {self.client_id}")
                return True
        logger.error(f"Handshake failed: {response.text}")
        return False

    def cometd_subscribe_all(self, cometd_url):
        # Subscribe to all CDC channels one by one, using replayIds from Azure Blob checkpoints.
        replay_ids = {}

        for channel in self.channels:
            # Construct Azure-safe blob name
            blob_name = f"Checkpoint{channel.replace('/', '_').replace(':', '')}.json"
            blob_client = BLOB_SERVICE_CLIENT.get_blob_client(container=CHECKPOINT_CONTAINER, blob=blob_name)

            try:
                # Attempt to read the blob content
                blob_data = blob_client.download_blob().readall()
                replay_id = json.loads(blob_data).get("replayId")
                replay_ids[channel] = replay_id
            except ResourceNotFoundError:
                replay_ids[channel] = None
                logger.info(f"No checkpoint found for channel {channel}. Starting fresh.")
            except (json.JSONDecodeError, Exception) as e:
                replay_ids[channel] = None
                logger.error(f"Failed to load checkpoint for channel {channel}: {e}", exc_info=True)

        def build_payload(channel, replay_id):
            return {
                "channel": "/meta/subscribe",
                "clientId": self.client_id,
                "subscription": channel,
                "ext": {
                    "payload.format": "FULL",
                    "replay": {channel: replay_id}
                }
            }

        final_channels = []

        for channel in self.channels:
            current_replay_id = replay_ids[channel] if replay_ids[channel] is not None else -1
            payload = build_payload(channel, current_replay_id)

            response = self.session.post(cometd_url, json=[payload])
            if response.status_code != 200:
                logger.error(f"Failed to connect to channel {channel}. HTTP {response.status_code}: {response.text}")
                continue

            results = response.json()
            for result in results:
                result_channel = result.get('channel', '')

                if result_channel.startswith("/meta/"):  # Subscription confirmation
                    if result.get('successful'):
                        logger.info(f"Subscribed to channel: {channel} with replayId={current_replay_id}.")
                        final_channels.append(channel)
                    else:
                        error = result.get('error', '')
                        logger.warning(f"Subscription failed for {channel} with replayId={current_replay_id}: {error}")

                        if "invalid" in error.lower() and "replayid" in error.lower():
                            logger.info(f"Retrying subscription for {channel} with replayId = -1")
                            retry_payload = build_payload(channel, -1)
                            retry_response = self.session.post(cometd_url, json=[retry_payload])
                            retry_result = retry_response.json()[0]
                            if retry_response.status_code == 200 and retry_result.get('successful'):
                                logger.info(f"Subscribed to channel: {channel} with replayId = -1 after retry")
                                final_channels.append(channel)
                                save_replay_id(channel, -1)
                            else:
                                logger.error(f"Retry failed for {channel}: {retry_response.text}")
                        elif "403::User not allowed" in error:
                            logger.error(f"Permission denied for channel {channel}. Skipping.")
                        else:
                            logger.error(f"Unknown error for channel {channel}: {error}")
                            logger.warning(f"Subscription result: {result}")

                elif result_channel.startswith("/data/"):  # Data message bundled in subscription response
                    logger.info(f"Received data event for channel {result_channel}: {json.dumps(result)}")
                    self.on_message(result)

        self.channels = final_channels
        return bool(final_channels)

def cometd_connect(self, cometd_url):
        # Maintain single long-polling connection for all channels.
        MAX_RUNTIME = 260  # 4m20s for a 5m timeout (40s buffer)
        start_time = time.time()

        while True:
            # Timeout check at the start of each iteration
            elapsed = time.time() - start_time
            if elapsed > MAX_RUNTIME:
                logger.info("Approaching function timeout - exiting gracefully")
                return True  # Graceful exit, run() will treat as successful

            try:
                connect_payload = [{
                    "channel": "/meta/connect",
                    "clientId": self.client_id,
                    "connectionType": "long-polling"
                }]

                response = self.session.post(cometd_url, json=connect_payload, timeout=40)

                if response.status_code == 200:
                    messages = response.json()
                    for message in messages:
                        if message.get('channel') in self.channels:  # CDC event
                            self.on_message(message)
                        elif message.get('error') == '403::Unknown client':
                            logger.warning("Client expired, reconnecting...")
                            return False
                else:
                    logger.error(f"Connect failed: {response.text}")
                    time.sleep(10)

            except requests.exceptions.ReadTimeout:
                logger.info("Long-polling timeout reached, re-establishing connection...")
                continue  # Immediately try again

            except requests.exceptions.RequestException as e:
                logger.error(f"Connect error: {e}")
                time.sleep(10)

            except Exception as e:
                logger.error(f"Unexpected error: {e}")
                time.sleep(10)
